Solar Marine Lantern Installation Case: AH-LS-C IP68 IALA Navigation Lights

Q&A: Solar Marine Lantern Installation

Q1 Where is it used? On buoys, lighthouses and offshore or river sites for night navigation marks.

Q2 Is external power needed? No. It is fully self-contained: a 1.8 W solar panel charges a 3.7 V lithium-ion battery, giving 60 h steady or 150 h flashing autonomy.

Q3 What visibility does it give? 360° output, 7° vertical divergence, 1-3 NM range, in red, green, yellow, white or blue per IALA E-200-1.

Q4 How is it installed? A 1 kg unit mounts on a 140×140 mm base with 4×M6 bolts; the ON/OFF button sits below and the photocell runs dusk-to-dawn flashing, default FL3S(0.2,2.8).

Q5 Maintenance and options? LED life exceeds 100,000 h with about 3 years of battery life; a bird spike protects the lens, and GPS sync, IR programmer for 366 IALA characters and external charging are optional.
